Khoom Parameters
| Yam khoom | Specification |
|---|---|
| Khoom siv | 1045 Carbon Steel, 5140, 4340 Alloy Steel |
| Txoj Kev Forging | Kaw -Tuag, Precision Forging |
| Daim ntawv thov | Automotive, industrial, khoom siv fais fab |
| Kev kho cua sov | Normalized, Q&T, Case-Hardened |
| MOQ | 10 pcs |
piav qhia
Forged txuas rods txuas lub piston mus rau lub crankshaft nyob rau hauv lub combustion engines - txhais lus reciprocating rau hauv rotary motion. Cov pas txuas txuas tau ntsib ob qho tib si compressive thiab tensile loads los ntawm txhua lub zog stroke, thiab tsis ua hauj lwm ua rau lub cav puas. Forged txuas rods muaj zog dua cam khwb cia los yog hmoov hlau rods, ua forged tus qauv rau kev ua tau zoo thiab hnyav- daim ntawv thov. Kaw- tuag forging ua rau I-beam cross-section zoo nrog cov nplej zoo. Qhov loj kawg thiab me me kawg bores yog tiav machined kom nruj tolerances rau bearing haum. 1045 carbon steel yog cov khoom siv tshaj plaws rau kev sib txuas qws forgings{10}} alloy steel muab lub zog ntau dua thiab qaug zog rau kev ua haujlwm thiab hnyav{11}} daim ntawv thov.
I-Beam vs. H-Beam txuas Rods
I-beam txuas rods yog sib dua rau tib lub zog - qhov I-beam cross-section siv cov khoom zoo rau khoov tsis kam. H-beam txuas rods muaj ob txoj kab sib txuas uas muab thaj chaw ntau dua rau piston-tus pin tus thawj sib cuag thiab nruj dua nyob rau hauv cov khoom ntim. Rau siab -RPM daim ntawv thov, I-beam feem ntau sib dua thiab txaus. Rau siab- txhawb nqa, siab- lub cav torque qhov twg tus pas nrig pom cov khoom hnyav hnyav, H-beam muab qhov nruj ntxiv uas xav tau.
FAQ
Q1: MOQ?
A1: 10 daim rau tus qauv forging ntau.
Q2: Khoom siv?
A2: 1045 carbon steel, 5140, 4340 alloy steel.
Q3: Forging txoj kev?
A3: Kaw-tuag precision forging kom zoo ib yam thiab cov qauv nplej.
Q4: Kev kho cua sov?
A4: Normalized, quenched thiab tempered, los yog rooj plaub-hardened raws li daim ntawv thov.
Q5: Kev cai configuration?
A5: Yog. Kev cai pas nrig ntev, qhov ntau thiab tsawg, thiab nqaj profiles.
Q6: Kev lees paub zoo?
A6: Yog. Magnetic particle soj ntsuam thiab hardness pov thawj muaj.
Zoo tsis yog -negotiable nyob rau hauv precision manufacturing. Txhua yam khoom raug soj ntsuam nruj ntawm txhua theem ntawm kev tsim khoom.
- TIAB SA 16949- Automotive zoo tswj system rau kev nyab xeeb- cov khoom tseem ceeb
- PIB / PPF- Cov ntaub ntawv pov thawj ntawm Cov Txheej Txheem Ntau Lawm muaj nyob rau ntawm kev thov
- AIAG Core Tools- APQP, FMEA, SPC, thiab MSA cov ntaub ntawv ntawm kev thov
- Kev tshuaj xyuas CMM- Coordinate ntsuas rau complex geometry thiab nruj tolerances
- Nto Roughness Measurement- Ra, Rz, thiab Rt daim ntawv qhia nrog txhua daim ntawv tshuaj xyuas
- Passivation / Electropolishing- ASTM A967 cov txheej txheem rau corrosion kuj
- Khoom siv Traceability- Kev ntsuas kub ntawm cov khoom siv raw mus rau qhov ua tiav
Los ntawm raw khoom mus rau cov khoom tiav, txhua kauj ruam yog tswj thiab sau tseg:
- Billet Cua sov- Precision cua sov rau forging kub nrog ntsuas kub
- Forging- Kaw-tuag, qhib- tuag, lossis lub nplhaib dov mus ze rau -net shape
- Trimming / Piercing- Flash tshem tawm thiab ua haujlwm bore
- Kev kho cua sov -Los ntawm -hardening, case-hardening, los yog hnub nyoog- hardening raws li xav tau
- Finishing Machining- CNC machining, sib tsoo, lossis super-ua tiav rau qhov kawg qhov ntev
- Kev kho saum npoo- Anodizing, plating, lossis txhaj tshuaj peening raws li tau teev tseg
- Kev Tshawb Fawb & Kev Xeem- Dimensional check, hardness testing, deg soj ntsuam
- Ntxuav & Ntim- Degreasing, tiv thaiv xeb, thiab tiv thaiv ntim
